测试项目 Test Items |
测试标准 test standard |
单位 unit |
规格(specifications) | ||||||
标准 standard |
方法 method |
LSCF120 | LSCF150 | LSCF170 | LSCF220 | LSCF350 | |||
组织 weave |
平纹 Plain 1/1 |
平纹 Plain 1/1 |
平纹 Plain 1/1 |
平纹 Plain 1/1 |
平纹 Plain 1/1 |
||||
幅宽 width |
ISO3932 | cm | >120 | >120 | >120 | >120 | >120 | ||
厚度 thickness |
ISO5084 | 1,test disk=2000mm2 2,Pressure=1 Kpa |
mm | 0.30±0.1 | 0.35±0.1 | 0.5±0.1 | 0.65±0.1 | 0.85±0.1 | |
重量 weight |
ISO3801 | 24h at 20℃,65% | g/m2 | 120±20 | 150±20 | 170±20 | 220±20 | 220±20 | |
比表面积 Specific surface area |
m2/g | 300-400 | 300-400 | 700-800 | 300-400 | 300-400 | |||
厚度电阻 Electrical resistance(vertical) |
D-6120 |
1,test area=5cm×5cm 2,Pressure=15 kg |
Ω | <0.02 | <0.02 | <0.2 | <0.03 | <0.03 | |
方阻 sheet resistance |
D-6120 | Ω | 3-5 | 3-5 | 35 | 3-5 | 3-5 | ||
密度 density |
经向 warp |
ISO7211-2 | End/10cm | 38±5 | 40±5 | 38±5 | 43±5 | 63±5 | |
纬向 weft |
28±5 | 30±5 | 28±5 | 38±5 | 58±5 |
